Experiment # P205 General College Physics I
Dr. Ahmad Ballistic Pendulum Date:________
Name:_________________________
Group Names:______________________________________
Object: To determine the velocity of a projectile by means of a ballistic pendulum apparatus.
Apparatus: Ballistic pendulum
apparatus, steel ball, balance and measuring tape.
Theory:
Fig.1. Bullet of mass m colliding with a Ballistic
pendulum of mass M
1.
A bullet of mass m travelling with a velocity
V in the x-direction strikes the Ballistic pendulum of mass M initially at
rest.
2.
Just after the collision in which the bullet is captured by the
pendulum, the velocity of the two together is V1.
3.
According to conservation of momentum
mV
= (m + M) V1 ………
(1)
4. The bullet-pendulum combination originally at a height Y1 rises
to a height Y2 above the reference level shown. Kinetic energy is not conserved in this
collision. However, the kinetic energy
of the bullet-pendulum combination is converted to the potential energy when it
rises to a height of (Y2 - Y1). Then
(1/2)(m + M)V12 =
(m + M).g.(Y2 - Y1) ……(2)
5. Solving (1) and (2) we get:
V1 = Ö (2g (Y2 - Y1)) and V = (m + M)V1
/ m
Procedure:
(a)
Ballistic Pendulum:
1.
Slide the projectile ball onto the rod of the spring gun. Measure Y1,
the height of the center of the ball above the base of the apparatus.
Cock the gun by pushing against the ball until the latch catches.
2.
Fire the ball into the stationary pendulum.
3.
The pendulum will swing up and then lodge in the notched track. Measure the distance Y2 of the
center of the ball above the base of the apparatus.
4.
Repeat the above procedure for a total of five trials.
Observations:
Mass of pendulum assembly M
=
TABLE I Ballistic pendulum
Trials
|
|
Y1 m |
Y2 m |
Velocity V1 m/s |
Velocity V m/s |
1. |
|
|
|
|
|
2. |
|
|
|
|
|
3. |
|
|
|
|
|
4. |
|
|
|
|
|
5. |
|
|
|
|
|
Calculations: Complete the last two columns of the table.
Result: Report your results in a brief statement.
Sources of Error: Write down the
sources of error in this experiment.
