Plate X. Medulla oblongata at the level of the dorsal cochlear nucleus

A. Inferior vestibular nucleus
B. Medial vestibular nucleus
C. Nucleus prepositus
D. Solitary fasciculus
E. Solitary nucleus
F. Nucleus ambiguus
G. Fascicles of glossopharyngeal nerve
H. Spinal trigemnial tract
I. Spinal trigeminal nucleus
J. Ventral trigeminothalamic tract
K. Central tegmental tract
L. Inferior olivary nucleus
M. Interolivary fibers
N. Olivocerebellar fibers
O. Inferior cerebellar peduncle
P. Rubrospinal tract
Q. Pyramidal (corticospinal) tract
R. Ventral spinocerebellar tract
S. Spinal lemniscus (spinothalamic and spinotectal tracts)
T. Dorsal cochlear nucleus
U. Medial longitudinal fasciculus
V. Tectospinal tract
W. Medial lemniscus
X. Dorsal longitudinal fasciculus
